THERMO-DIFFERENTIAL DETECTOR - CONVENTIONAL FIRE DETECTION - BF302Z1
Extremely reliable thermodifferential fire detector of conventional technology, 9-33 VDC. C-TEC, BF302Z1 (LPCB Approved)
-
- Wide 9-33V operating voltage.
- Easy to install and maintain - the BF308Z smooth action, one-way fit base has no electronic parts virtually eliminating the risk of damage during installation.
- Advanced electronic technology.
- Attractive common design - all Series 65 detectors have the same sleek external dimensions and are housed in a robust white polycarbonate moulding.
- Proven detection performance.
- Low current draw - quiescent current draw is only 28uA on optical, 40uA on ionisation and 45uA on heat detectors.
- Designed to meet approvals worldwide.
- Polarity insensitive - identification of +Ve and –Ve lines is only required when connecting detectors to remote LEDs.
- Interchangeable design - Any Series 65 detector can be replaced with another.
- For example, a smoke detector unsuitable for use in a particular application can be easily replaced with a heat detector.
- Highly visible alarm indication - provided via a protruding LED on all detector heads.
- Tested and approved to EN54-7:2000 (optical and ionisation smoke detectors) and EN54-5:2000 (heat detectors).
- Compliant with the essential requirements of the EMC Directive 98/336/EEC and the Construction Products Directive 89/106/EEC.
