INDUCTIVE CARDS READER ROSSLARE AY-K14

Excellent inductive card reader, (Clock & Data), witch has a light and optical tamper, anti-vibration and waterproof, suitable for outdoor or indoor installation.

ELECTRICAL CHARACTERISTICS

• Operating Voltage Range:
5-16 VDC, from a regulated power supply.

• Input Current: Standby:
35mA at 12 VDC Maximum: 50mA at 12 VDC

• LED Control:
Dry Contact, N.O.

• Proximity:
Maximum read range*: 80mm (3.15") Modulation: ASK at 125 kHz Compatible cards: All 26-Bit EM Cards * Measured using Rosslare Prox Card AT-R14 or equivalent. Range also depends on electrical environment and proximity to metal.

• Tamper:
Optical back tamper sensor, O.C. active low 16mA max sink current OPERATIONAL CHARACTERISTICS

• Output Format:
Clock & Data

• Audio/Visual:
Bi-colored LED indicator, Built-in sounder

• Design:
Epoxy potted, fully sealed in a rugged polycarbonate enclosure. Suitable for harsh environments. ENVIRONMENTAL CHARACTERISTICS

• Operating Environment:
Water resistant, suitable for outdoor use (IP65 rated)

• Operating Temperature:
-31?C to 63?C (-25?F to 145?F)

• Operating Humidity:
0 to 95% (non-condensing)

• RFI Protection:
> 20 V/m up to 1000 MHz PHYSICAL CHARACTERISTICS

• Dimensions:
80mm x 40mm x 12.8mm (3.1" x 1.6" x 0.5")

• Weight:
70.5g (0.155 lbs)
