SWITCH 16-PORT PoE WITH 8-PORT ePoE DH-LR2218-16ET-240
Extremely useful and quality switch that has 16 PoE ports and 8 ePoE ports capable of delivering PoE transmission to over 800m of Ethernet cable at 10Mbps. It also supports PoE and PoC power supply technology, or has a very simplified construction and wiring.
· Supports long distance PoE transmission up to 800m with
ePoE technology of Dahua
· Layer-two web managed ePoE switch
· Port 1-8 support three self-adaptive transmission modes
which are IEEE, E100 and E10
· Port 1-8 support both twisted-pair transmission and coaxial
cable transmission
· Support web management: port management, 802.1Q
VLAN, STP/RSTP, LACP, 802.1X, QoS
· Support PoE management, Green PoE, Legacy Support
· Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and
IEEE802.3X standards
-
Model
DH-LR2218-16ET-240Ethernet Port2*10/100/1000 Base-T2*1000 Base-X (Combo ports)16*10/100 Base-T (PoE power supply)
PoE Power Consumption
Port1 and port 2 support Hi-PoE 60WEach power≤30W, Total≤240W
PoE Protocol
IEEE802.3af, IEEE802.3at, Hi-PoE
Switching Capacity
8.8Gbps
Packet Forwarding Rate
5.36Mpps
Packet Buffer Memory
2.75Mb
Application Humidity
10%~90%
Power
AC100-240V, 50/60Hz
Lightning Protection Common Mode
4KV
Differential Mode
2KV
Working Temperature
-10°C~55°CWeight
3.12kg
Dimension(W×D×H)
440mm x300mm x44mm
